Twin-lift Hydraulic Spreader
current location: Home / Product > Twin-lift Hydraulic Spreader

Short Description:

The main features of the double-box separable spreader are a set of intermediate lifting devices in the middle of the main beam of the spreader, which can lift two 20-foot standard containers at the same time.Compared with the double-box separable spreader (movable guide) spreader, the spreader is only different from the guide plate with four corners. This spreader is suitable for the bridge proje


INQUIRY NOW 联系我们获取更多信息

我们能为您提供更多的选择方案

MIC banner-2





Twin-lift sparated spreader has advanced technology. We aim at satisfying user's requirements. According to the using information of the products, we use the latest eletromechanical and hydraulic basic elements to improve our products persistently.



The structures of the whole spreader are made by high-quality and high-strength steel. The force alalysis is carried out to ensure that the material is used reasonable. It makes the spreader which has high strength, long operating life and light weight, it can adapt to the bad work condition requirements of ports.



【型号/Model:QSHI】

总功率

≤ 8KW

Total power

适用于操作   ISO标准   20’   ,40’ , 45’ 和两个 20’ 集装箱

防护等级

IP 55

For operation with ISO standard   20',40'

,   45'   and twin 20' containers

Precaution class

额定起重量  (同心 /单箱 )

50T

系统工作压力

100 /170 bar

S.W.L.(Concentric/Single mode)

Operating pressure of the system

额定起重量  (偏心 /双箱 )

65T

环境温度

-20℃ ~+45℃

S.W.L.(Eccentric/Twin20’mode)

Ambient   temperature

四角吊耳负重

16.25t×4

【转销形式】

ISO浮动转销,油缸驱

Load of lifting lugs at four   corner

Twistlock Mode

ISO floating twistlock, driven   by an oil cylinder

自重  (吊具部分 )

【伸缩驱动方式】

液压马达链传动The telescopic system  is    driven by

13t

Self-weight (spreader)

Telescopic Mode

means of an hydraulic motor   connected to an endless chain.

伸缩   (20’ 到 45’ )

【导板装置】

可拆卸式导板

~ 35S

Expansion time (20’ to 45’ )

Flippers Device

knock-down flipper

转销   (

90°)

【中间转销箱】

油缸垂直运动实现升降

Twistlock

rotation  through    90

< 1 S

M id d le T w   i st l o c k

Raised and   lowered by vertical movement of hydraulic cylinders

°

H o usin g s

电源电压   /频率

AC 380V(3P)/50HZ

油缸水平运动实现平移

Power voltage/ Frequency

(可选 / as agreed)

Moved by horizontal movement of   hydraulic cylinders.

控制电压

DC 24V

【适用】

轨道吊,轮胎吊

Control voltage

Application

RMG, RTG
