Full Load Luffing Crane
Technical characteristics
This machine is a fixed installation, 360° rotary full load variable amplitude crane. It has the characteristics of reasonable structure, flexible operation, convenient maintenance and high work efficiency.
The lifting device of the machine has three types of hooks (single cable), grab bucket (double cable) and four ropes. The variable amplitude device has three types of wire rope, rack and four links for users to choose, which can be realized during operation. The horizontal displacement of the cargo makes the operation simpler, safer and more reliable.
Design specification
This model is designed and manufactured according to "GB3811-83 Crane Design Specification" and "GB6067-85 Crane Safety
Regulations".
Technical Parameters
| Parameters | Unit | QSHI 5-25 | QSHI 10-25 | QSHI 16-25 | QSHI 20-30 | QSHI 40-30 | QSHI 50-30 | QSHI 150-40 | |
| Rated lifting capacity | t | 5 | 10 | 16 | 20 | 40 | 50 | 150 | |
| Working range | m | 7 ～ 25.0 | 7 ～ 25.0 | 7 ～ 25.0 | 8 ～ 30.0 | 8 ～ 30.0 | 8 ～ 30.0 | 8 ～ 30.0 | |
| Lifting height | Base surface | m | 16 | 16 | 16 | 20 | 20 | 20 | 30 |
| Under the base | 10 | 10 | 10 | 10 | 10 | 10 | 10 | ||
| Lifting speed | m /min | 10～60.0 | 10～60.0 | 10～60.0 | 6～60.0 | 6～20.0 | 6～20.0 | 2～10.0 | |
| Variable speed | m /min | 6～40.0 | 6～40.0 | 6～40.0 | 3～40.0 | 3～18.0 | 3～18.0 | 3～18.0 | |
| Rotate speed | r /min | ≈2.00 | ≈2.00 | ≈2.00 | ≈2.00 | ≈1.50 | ≈1.20 | ≈0.8 | |
