Short Description:
QSFT300 mobile container is designed for small and medium-sized container freight yard, small and medium enterprises container shipments. It has the lowest operating costs The main function is to load the container from the container flatbed and lift the container to the container flatbed to the workplace, the operator can be loaded into the container in a continuous manner. At the same time, with the container for transit, greatly reducing the container truck waiting for loading time, which can improve the efficiency of container trucks 12 to 15 times.
联系我们获取更多信息
我们能为您提供更多的选择方案
It uses 490BPG diesel engine as the driving force, with low noise, small vehicle vibration characteristics. The main body consists of steel structure frame, steel wire rope, hydraulic motor of hydraulic transmission system, gear pump, steering cylinder, lifting cylinder, double acting balance valve, walking solid tire and so on.
Lifting with a diameter of 180 mm cylinder, lifting weight is big, the system pressure is small, lifting and down are stable, safe, and is highly efficient in loading and unloading. Using two-wheel drive, four-wheel steering, the maximum angle of up to 110 degrees, which can achieve any angle of steering and translation, turning radius is small.
The control system consists of a complete set of valve body and operating rod, convenient and flexible operation, simple and convenient. The mobile container crane is required to be used in flat, hardened ground Applicable to the logistics company, warehouse, terminal, container yard, freight yard and other places of the container handling. It is a good-quality and cheap, convenient and practical container lifting equipment.
| Model | QSFT300 | QSFT350 | QSFT400 | |
| Performance parameters | ||||
| dead weight（T） | 7 | 7.5 | 8 | |
| Rated lifting capacity（T） | 30 | 35 | 40 | |
| Container size（ft） | 20’ | 20’ | 40’ | |
| Maximum travel speed(no load)(km/h) | 3.5 | 3.5 | 3.5 | |
| Minimum channel width（mm） | 3200 | 3200 | 3200 | |
| Maximum lifting speed (m / min) | no load | 2.1 | 2.1 | 2.1 |
| Maximum descent speed (m / min) | 1.5 | 1.5 | 1.5 | |
| Maximum lifting speed (m / min) | full load | 1.5 | 1.5 | 1.5 |
| Maximum descent speed (m / min) | 1.8 | 1.8 | 1.8 | |
| Engine power （kw） | 37 | 37 | 37 | |
| Hydraulic motor rated torque（Nm） | 1010 | 1010 | 1010 | |
| System pressure（MPa） | 14 | 15 | 16 | |
| Steering wheel rotation angle（°） | 110 | 110 | 110 | |
| Structural parameters | ||||
| Length × width × height（mm） | 5055×2655×6320 | |||
| The maximum height of the hanging beam（mm） | 4660 | 4660 | 4660 | |
| The minimum height of the hanging beam（mm） | 2270 | 2270 | 2270 | |
| Minimum ground clearance（mm） | 110 | 110 | 110 | |
| Longitudinal wheel spacing（mm） | 2205 | 2205 | 2205 | |
| Horizontal wheel spacing（mm） | 3725 | 3725 | 3725 | |
| Horizontal width（mm） | 3275/3380 | 3275/3380 | 3275/3380 | |
| Wire rope diameter（mm） | 28 | 28 | 28 | |
| Tire specifications（mm） | 450×180 | 450×180 | 450×180 | |
