Advantages:
• Advanced AC control system with MOSFET delivers smooth driving speed control for precise.
• Small turning radius,easy and smart to operate.
• Lean-on compartment reducing operator’s fatigue.
• With regenerative braking system for driving and electronic braking system for parking.
• Low Battery Protection setting prolongs service life .
• With deadman switch on floor to cut off the power when operator leave the foot from cab.
• Lifting cylinders on the both of mast provides best visibility.
• The optional of Full Hydraulic Steering System and Electric Power Steering(EPS) offers follow advantages:
Steering wheel automatic reset.
Travelling speed automatically slow down when steering.
Show the turning angles on the display.
Model | CPD10A | CPD10AC | CPD10B | CPD10BC | CPD10BZ | |
Power | battery | battery | battery | battery | battery | |
Capacity/rated load | Q(kg) | 1000 | 1000 | 1000 | 1000 | 1000 |
Load centre distance | c(mm) | 600 | 600 | 500 | 500 | 500 |
Max.lift height | h3(mm) | 3000 | 3000 | 5000 | 5000 | 5000 |
Load distance, centre of drive axle to fork | x(mm) | 140 | 205 | 180 | 210 | 186 |
Tyre size, front | mm | Φ250×80 | Φ250×80 | Φ250×80 | Φ250×80 | Φ250×80 |
Tyre size, rear | mm | Φ280×100 | Φ280×100 | Φ280×100 | Φ280×100 | Φ280×100 |
Variation of side shifter, left/right | mm | 0 | 100/100 | 0 | 100/100 | 0 |
Height,mast lowered | h1(mm) | 2155 | 2155 | 2255 | 2250 | 2250 |
Free lift | h2(mm) | 1600 | 1600 | ~ | ~ | 1600 |
Height, mast extended | h4(mm) | 3565 | 3565 | 5600 | 5600 | 5600 |
Height of overhead guard(cabin) | h6(mm) | 2090 | 2090 | 2090 | 2090 | 2090 |
Height of tiller in drive position min./max. | h14(mm) | 1000 | 1000 | 1000 | 1000 | 1000 |
Overall length | l1(mm) | 2210 | 2270 | 2250 | 2290 | 2290 |
Overall width | b1(mm) | 890 | 890 | 890 | 890 | 890 |
Fork dimensions | s/e/l(mm) | 35/100/950 | 35/100/950 | 35/100/950 | 35/100/950 | 35/100/950 |
Fork carriage DIN 15173, class/type A,B | ll/A | ll/A | ll/A | ll/A | ll/A | |
Fork-carriage width | b3(mm) | 560 | 560 | 560 | 560 | 560 |
Ground clearance, centre of wheelbase | m2(mm) | 50 | 50 | 50 | 50 | 50 |
Aisle width for pallets 1000×1200 croossways | Ast(mm) | 2700 | 2760 | 2750 | 2820 | 2800 |
Aisle width for pallets 800×1200 lengthways | Ast(mm) | 2810 | 2870 | 2860 | 2930 | 2910 |
Turning radius | Wa(mm) | 1200 | 1200 | 1250 | 1300 | 1300 |
Travel speed, laden/unladen | Km/h | 5.8/6.0 | 5.8/6.0 | 5.8/6.0 | 5.8/6.0 | 5.8/6.0 |
Lift speed, laden/unladen | m/s | 0.11/0.15 | 0.11/0.15 | 0.15/0.25 | 0.15/0.25 | 0.15/0.25 |
Lowering speed, laden/unladen | m/s | 0.15/0.11 | 0.15/0.11 | 0.08/0.10 | 0.08/0.10 | 0.08/0.10 |
Battery voltage,nominal capacity K5 | V/Ah | 24/360 | 24/360 | 24/360 | 24/360 | 24/360 |
Battery weight | Kg | 355 | 355 | 355 | 355 | 355 |
Battery dimensions l/w/h | mm | 610x278x740 | 610x278x740 | 610x278x740 | 610x278x740 | 610x278x740 |
Service weight(with battery) | kg | 2120 | 2180 | 2230 | 2320 | 2350 |
